Mobility Scooter - Series C

Description

Providing safe mobility assistance, the Vive Mobility Series C Mobility Scooter easily navigates over smooth, indoor and outdoor surfaces such as concrete, pavement, tile and carpeting. Our electric scooter weighs approximately 114.6 pounds and includes a wide, padded seat and backrest that is height adjustable for maximum comfort, 8” flat-free tires with a ground clearance of 3.5” and a front-mounted storage basket for carrying everyday items. With a top speed of 5 mph, the Series C mobility scooter has a driving range of up to 15.5 miles per charge.

Features

• Easily Maneuver Indoors and Out
  Providing a smooth, comfortable ride, the Vive Mobility Series C Mobility Scooter is perfect for navigating in your home, at the market and on the go. With a ground clearance of 3.5”, the electric scooter easily clears most door jambs and smoothly rolls over flooring changes on four, 8.86” flat-free tires.

• Go Farther on A Single Charge
  Our Series C personal mobility scooter is powered by a long-lasting, rechargeable battery pack with a range of up to 15.5 miles per charge and a top speed of 5 mph. Your mobility scooter includes a quick connect battery and charging cable.

• Ride in Comfort and Style
  Our Series C power scooter is designed for comfort, safely supporting up to 300 pounds with a large platform and height-adjustable captain's seat. Comfortably padded, the wide, 16.54” seat and backrest provide gentle cushioning and support. Additionally, the scooter seat is surrounded by two padded armrests that adjust and flip upward for greater convenience when exiting or boarding.

• Wraparound Delta Tiller
  Equipped with a wraparound delta tiller and drive levers, the Vive Mobility Series  electric scooter’s intuitive control panel allows you to set the maximum speed with the variable speed dial and turn on the bright LED headlight as needed when navigating in low-light areas. The tiller display also includes a color-coded battery life indicator for checking the status of the battery at a glance.

General Specifications

• What’s Included:
• Scooter
• Light
• Basket
• Battery
• Color(s): Red or Blue
• Product Material(s): Plastic and Steel
• Latex free: yes


Product Specifications

• Overall Dimensions: (L x W x H) 43.3” x 19.6” x 36.2”
• Seat Height: (from ground) 23” to 26”
• Seat Width: 17”
• Seat Depth: 16”
• Armrest Height: (above seat) 8.2”
• Seat Back Height: 23.25”
• Net Weight: 114 lbs.
• Maximum Speed ≤4.9 mph
• Maximum Braking Distance ≤59”
• Minimum Turning Radius ≤4.9ft
• Weight Limit 300 pounds.
• Maximum Travel Distance: 15.5 mi
• Static Stability ≥ 9°
• Dynamic Stability ≥ 6°
• Climbing Ability ≥ 9°
• Transaxle 24V/250W
• Battery Lead-acid battery: (24V/20AH)
• Controller Maximum output current: 45A
• Controller Minimum output current: 2A
• Front Wheel Diameter: 8.8” (Solid)
• Rear Wheel Diameter: 8.8” (Solid)

Warranty Chart

• Battery Case 60 days
• Wheels: On arrival 30 days
• Seat: On arrival 30 days
• Frame: 5 Years
• Batteries: 6 months
• Charger: 90 days
• Electrical: 6 months
• Keys: On arrival 30 days
• Horn & Controller: 6 months
• Paint: On arrival 30 days
• Screws: On arrival 30 days
• Handles: 90 days
