Pionner 10
Merits
- Regular price
- Price: $3,766.00
- Regular price
- List Price: $4,184.00
- Sale price
- Price: $3,766.00
- Unit price
- per
SKU:
Couldn't load pickup availability
Share
This Deal Ends In:
PRODUCT DESCRIPTION
Description
The Pioneer 10 was built with your safety in mind. The 4-wheel construction ensures stability while on the go, while the pre-set half-speed control on the scooter’s dashboard keeps you comfortable while driving. The Pioneer 10 comes with an automatic sensor, which lowers speed to half-speed when turning; assisting with sharp turns. The scooter’s frame features a heavy duty one-piece frame; great for the outdoors and uneven terrain.
Features
- Hydraulic, adjustable tiller
- 22”W x 20”D x 22”H, sliding, captain seat
- Half speed inhibit switch
- Headlight, tail lights, turn signals and hazard lights
- Four wheels provide more stability
- 4” ground clearance
Specification
| Product Number | S341 |
| Weight Capacity | 500 lbs |
| Seat Width | 22" |
| Seat Depth | 20" |
| Backrest Height | 22" |
| Seat-to-Ground Height | 25" - 28" |
| Seat-to-Deck Height | 16" - 19" |
| Overall Length | 59" |
| Overall Width | 27" |
| Overall Height | 47" |
| Turning Radius | 62" |
| Ground clearance | 4" |
| Weight of Heaviest Piece | 121 lbs |
| Total Weight | 269 lbs |
| Max Speed | 6 mph |
| Per Charge Range | up to 32 miles |
| Motor | DC 24V, 400W |
| Controller | Dynamic Rhino2 160A |
| Battery Size (2) | 12V/Group 24 (70-80AH) |
| Charger | 6A off-board |
| Gradient | 12° |
| Front Wheel(s) | 4-Wheel: 12.5" flat-free |
| Rear Wheels | 12.5" flat-free |
| Suspension | Yes |
| HCPCS Code | K0899 |
Warranty
MERITS HEALTH PRODUCTS, INC. WARRANTY POLICY
Merits Health Products, Inc. will repair or replace the following item(s) that have a manufactured
defect. Credit will be given following inspection by an authorized representative of Merits Health
Products, Inc. into the material or workmanship.
Part(s) purchased outside of warranty have 30 days to report manufactured defect.
5-Year Warranty from the original date of consumer purchase:
- Frame
18-Month Warranty from the original date of consumer purchase:
- Joystick
- Charger
- Gearbox
- Transaxle
- Electrical Harness
- Motor Brake Assembly
13-Month Warranty from the original date of consumer purchase:
- Seat Post
- Caster Forks
- Power Seat Actuator
- Metal Seating Frame
- Caster Beam
- Anti Tipper Forks
- Armrest Bracket (metal part only)
- 31ah or above batteries
6-Month Warranty from the original date of consumer purchase:
- Bearings
- Swivel Seat Mechanism
- Front Riggins
- Batteries less than 31 ah supplied by Merits Health
- Bushings Products, Inc.
Warranty Exclusions: The following item(s) are excluded from warranty:
- Tires and tubes
- Upholstery including seating/arm pads/padding
- Plastic and rubber part(s)
- Painted surfaces including shrouds/fenders
- Fuses and bulbs
- Battery cases
- Motor brushes
- Brake pads
Warranty becomes invalid on any parts damaged from:
- Acts of nature
- lost, or stolen
- Commercial use
- Neglect, improper operation, and/or maintenance or repair
- Units altered or serviced by an agency not authorized
by Merits Health Products, Inc - Serial numbered products if the serial number has been removed or defaced
Warranty Service:
Merits Health Products, Inc. retains the right to replace warranted part(s) with either refurbished or new part(s) at their discretion. Any costs related to labor, service calls, transportation, freight, or other charges associated with the installation of warranted part(s) are the responsibility of the consumer/dealer.
This warranty gives you specific rights and you may also have other rights which may vary from state to state.
