Description
The Vision Sport electric wheelchair is a very comfortable wheelchair to use for everyday outings. This mid-wheel power wheelchair uses a full suspension for optimum stability, durability, and reliability while giving you a smoother ride. With a turning radius of 20 inches, you can make turns with ease. Equipped with solid 6-inch tires on the front and rear and 10-inch in the middle, you will not get a flat tire on the go.
Features
- True mid-wheel drive: 20.6″ turning radius
- Robust independent suspension can absorb up to 250 lbs on the footplate without tipping forward
- Premium, semi-reclining ergonomic seat; up to 135°
- Dynamic LiNX controller for convenient Bluetooth programming and diagnostics
- 16″ seat width with 16″ – 18″ depth adjustability, 18″ – 20″ seat widths with 18″ – 20″ depth adjustability
- Includes red or blue shrouds
Options
- Unoccupied transit tie down kit
- 18″or 20”W x 18″or 20”D x 21”H seat
- 7.5” power seat lift
- Swing-away joystick
- USB Charger
- Elevating legrests
- Oxygen tank holder
- Foldable rear basket
- Walker holder
- Cane & crutch holder
Specifications
Product Number | P326A, P326D w/lift |
Weight Capacity | 300 lbs |
Drivetrain | MWD |
Seat Type | Captain or Pan |
Seat Width | 16”-20" |
Seat Depth | 16"- 20" |
Backrest Height | 20" |
Seat-to-Floor Height | A: 20.5”-22.5” D: 21.5"-29.5" |
Elevating Seat | P326D - 7.5" |
Overall Length | 34" |
Overall Width | 24" |
Overall Height | 48.5" |
Turning Radius | 20" |
Ground Clearance | 2" |
Total Weight | 184 lbs, 214 lbs |
Wt of Heaviest Pc | 90 lbs, 120 lbs |
Max Speed | 5 mph |
Per Charge Range | up to 18 miles |
Motor | DC 24V, 160W |
Controller | Dynamic LiNX 40A |
Battery Size (2) | 12V/U1 (34AH) |
Charger | 4A off-board |
Gradient | 6 ° |
Front Wheels | 6" solid |
Drive Wheels | 10" solid |
Rear Wheels | 6" solid |
Group | Group: 2 |
HCPCS Code | K0822/K0823 P326D: K0823 |
Standard Colors | Red or Blue |
Warranty
MERITS HEALTH PRODUCTS, INC. WARRANTY POLICY
Merits Health Products, Inc. will repair or replace the following item(s) that have a manufactured
defect. Credit will be given following inspection by an authorized representative of Merits Health
Products, Inc. into the material or workmanship.
Part(s) purchased outside of warranty have 30 days to report manufactured defect.
5-Year Warranty from the original date of consumer purchase:
- Frame
18-Month Warranty from the original date of consumer purchase:
- Joystick
- Charger
- Gearbox
- Transaxle
- Electrical Harness
- Motor Brake Assembly
13-Month Warranty from the original date of consumer purchase:
- Seat Post
- Caster Forks
- Power Seat Actuator
- Metal Seating Frame
- Caster Beam
- Anti Tipper Forks
- Armrest Bracket (metal part only)
- 31ah or above batteries
6-Month Warranty from the original date of consumer purchase:
- Bearings
- Swivel Seat Mechanism
- Front Riggins
- Batteries less than 31 ah supplied by Merits Health
- Bushings Products, Inc.
Warranty Exclusions: The following item(s) are excluded from warranty:
- Tires and tubes
- Upholstery including seating/arm pads/padding
- Plastic and rubber part(s)
- Painted surfaces including shrouds/fenders
- Fuses and bulbs
- Battery cases
- Motor brushes
- Brake pads
Warranty becomes invalid on any parts damaged from:
- Acts of nature
- lost, or stolen
- Commercial use
- Neglect, improper operation, and/or maintenance or repair
- Units altered or serviced by an agency not authorized
by Merits Health Products, Inc - Serial numbered products if the serial number has been removed or defaced
Warranty Service:
Merits Health Products, Inc. retains the right to replace warranted part(s) with either refurbished or new part(s) at their discretion. Any costs related to labor, service calls, transportation, freight, or other charges associated with the installation of warranted part(s) are the responsibility of the consumer/dealer.
This warranty gives you specific rights and you may also have other rights which may vary from state to state.
